InGaAs PIN Photodiode
New England Photoconductor offers a wide range of active areas and package types. We provide high responsivity, high shunt resistance and low capacitance. Custom InGaAs PIN Photodiode sizes are available.
|
Part Number |
I-.05 |
I-.10 |
I-.30 |
I-.50 |
|
Active Area um |
50 |
100 |
300 |
500 |
|
Responsivity @ 1300nm A/W Min/Typ |
0.80/0.90 |
0.80/0.90 |
0.80/0.90 |
0.80/0.90 |
|
1550nm A/W Min/Typ |
0.90/0.95 |
0.90/0.95 |
0.90/0.95 |
0.90/0.95 |
|
Dark Current @ 5V nA Max/Typ |
.07/.03 |
1.0/.05 |
5.0/1.0 |
25/5 |
|
Capacitance @ 5V pF Max/Typ |
0.6/0.4 |
1.2/1.0 |
8.0/4.0 |
40@0V |
|
Bandwidth 50Ω-3dB GHz Min @5V |
2.6 |
2.0 |
0.7 |
0.20 |
|
Rise/Fall time RL= 50Ω ns Max @ 5V |
0.08 |
0.1 |
0.25 |
0.50 |
|
NEP @ 1550nm W/√Hz Typ |
1.0E-15 |
1.5E-15 |
5E-15 |
8E-15 |
|
Storage Temperature ºC |
-40 to 125 |
-40 to 125 |
-40 to 125 |
-40 to 125 |
|
Operating Temperature ºC |
-40 to 85 |
-40 to 85 |
-40 to 85 |
-40 to 85 |
|
Reverse Voltage V |
25 |
25 |
25 |
20 |
|
ReverseC urrent mA |
1 |
10 |
10 |
10 |
|
Forward Current mA |
10 |
10 |
10 |
10 |
|
Package Options * (Note) |
CH-CE-46-46L |
CH-CE-46-46L |
CH-CE-46-46L |
CH-CE-46-46L |
|
Part Number |
I-1 |
I-2 |
I-3 |
I-5 |
|
Active Diameter mm |
1.0 |
2.0 |
3.0 |
5.0 |
|
Responsivity @ 1300nm A/W Min/Typ |
0.80/0.90 |
0.80/0.90 |
0.80/0.90 |
0.80/0.90 |
|
1550nm A/W Min/Typ |
0.90/0.95 |
0.90/0.95 |
0.90/0.95 |
0.90/0.95 |
|
Dark Current nA Max/Min |
100/25 @5V |
200/50 @5V |
500/20 @1V |
5000 @0.3V |
|
C @ 0V pF Max/Min |
120/80 |
500/300 |
600/100 |
1500/1000 |
|
C pF Max/Min |
50/30 @-5V |
150/100@3V |
300/250 @-2V |
3000/2000 |
|
Bandwidth 50Ω-3dB GHz |
40@5V |
5.3@0V |
4.0@0V |
1@0V |
|
T, RL= 50Ω ns Typ |
5.0@5V |
50@0V |
100@0V |
300@0V |
|
Res, MΩ Min/Typ |
10/50 |
6/30 |
2.0/8 |
0.025/0.050 |
|
NEP @ 1550nm W/√Hz Typ |
.01 |
.03 |
.05 |
.28 |
|
Linear Range (±.2dB)
dBm |
10 |
8 |
8 |
8 |
|
Storage Temperature ºC |
-40 to 125 |
-40 to 125 |
-40to 125 |
-40 to 125 |
|
Operating Temperature ºC |
-40 to 85 |
-40 to 85 |
-40 to 85 |
-40 to 85 |
|
Reverse Voltage V |
20 |
3 |
2 |
2 |
|
Reverse Current mA |
10 |
10 |
10 |
10 |
|
Forward Current mA |
10 |
10 |
10 |
10 |
|
Power Dissipation mW |
100 |
50 |
50 |
50 |
|
Package Options * (Note) |
CH-CE-46-46L |
CH-CE-5 |
CH-CE-5 |
CH-CE-8 |
